Spring Grinding Machine | CNC-H-1067-2-2S
Spring Grinding Machine | CNC-H-1067-2-2S
- To advance spring coiling accuracy inquiry by precision reducer drive.
- To save the grinding time by motor power current setup.
- To design the differential grinding speed on upper / lower grinding wheel adds the grinding accuracy.
- To advance the grinding effect by calibrating function.
| Wire Capacity(mm) | Ø 10.0~30.0 mm | |
| Max. Spring O .D.(mm) | Ø 250 mm | |
| Spring Length(mm) | 100~500 mm | |
| Production Speed(pcs/min) | 2~75 pcs / 25 min | |
| Plate Rate(rpm) | 0.5~30.0 rpm | |
| Grinding Wheel Rate(rpm) | 450 rpm | |
Machine Body Dimension(mm) Electronic Control Box And Screen Excluded | L | 2400 mm |
| D | 2800 mm | |
| H | 3600 mm | |
Safety Operation Location Area(mm) | L | 9000 mm |
| D | 6500 mm | |
| Machine Weight(kgs) | 12000 kgs | |
